360 rotary drum washing nozzles, 3d rotary tank cleaning nozzle

High impact 3D rotary tank washer

Model number: STD 2 drum washing nozzles





Working Principle:


Impeller is driven by cleaning fluid and drives internal reduction mechanism. Gear mechanism operates according to set track to realize the revolution and the rotation, thereby achieving 360° thorough cleaning.


Features & Benefits:



 ● Optimized structural design results in a water jet that produces greater impact

 ● Excellent sealing design, less than 3% leakage, thus saves cleaning fluid

 ● Independent gearbox design protects gear from damage and can work in poor water quality

 ● Overall optimized design,able to insert in small openings of 45MM







Application:
STD DG2 rotary tank washer is suitable for three-dimensional cleaning of small containers, such as oak barrels, beer barrels, 200L iron barrels, etc.
It is commonly used in petroleum, beverage,fuel ethanol, chemical,industrial fermentation,marine and where a high cleaning performance is required.
